high-end indoor applications

InnoFine Series

Product Header Image

  • larger LED chips deliver brightness up to 2,000 nits

  • innovative design reduces power consumption by 30%.

  • light transmittance up to 75%, enhancing clarity and color accuracy.

Download the Brochure

The InnoFine Series is built to deliver high brightness, energy efficiency, and ultra-reliable performance through advanced COB flip-chip and common cathode technology. With its patented surface coating and wide color gamut, InnoFine achieves outstanding image quality and durability, making it an ideal choice for high-end indoor applications where visual impact matters most.

  • Product Icon Image

    High Brightness

    up to 2,000 nits brightness with wide color coverage (DCI-P3).

  • Product Icon Image

    Energy Saving

    saves up to 30% power consumption compared to conventional LEDs.

  • Product Icon Image

    Long Lifespan

    COB technology with superior protection ensures long-term reliability.

Product Image 0

MicroLED high brightness, high contrast

MicroLED in 2000nits and 20000:1 contrast ratio.

Product Image 1

DCI-P3 Wide Color Gamut

delivers richer, more vibrant, and true-to-life colors for an exceptional visual experience.

Product Image 2

More Details at Low Brightness

MicroLED High Brightness, Hight Contrast. In 2000nits and 30000:1 contrast ratio.

Product Image 3

P0.9-P1.25-P1.56 COB

COB Flip Chip on Board, with ultra-small dot pitch and self-developed ink packaging process.

Product closing image 1

Specifications

Item
InnoFine007
InnoFine009
InnoFine012
InnoFine012-HB
InnoFine015
InnoFine018
Pixel Pitch (mm)
0.78125
0.9375
1.25
1.25
1.5625
1.875
Scanning Mode
54S
45S
45S
27S
54S
45S
Module Dimensions (mm) (WxH)
150 x 168.75
150 x 168.75
150 x 168.75
150 x 168.75
150 x 168.75
150 x 168.75
Cabinet Size (mm) (WxH)
600 x 337.5
600 x 337.5
600 x 337.5
600 x 337.5
600 x 337.5
600 x 337.5
Cabinet Resolution (WxH)
768 x 432
640 x 360
480 x 270
480 x 270
384 x 216
320 x 180
Led Configuration
COB
COB
COB
COB
COB
COB
Pixel Density (Dot/m²)
1,638,400
1,137,778
640,000
640,000
409,600
284,444
Gray Scale
13-22bit
13-22bit
13-22bit
13-22bit
13-22bit
13-22bit
Contrast
20000:1
30000:1
≥30000:1
≥30000:1
30000:1
30000:1
Brightness (cd/m²)
1000
1200
1200
3500
1200
1200
Module Quantity/Cabinet
8
8
8
8
8
8
Cabinet Material
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Die-casting Aluminum
Viewing Angle (Degree)
Horizon 160 Vertical 160
Horizon 160 Vertical 160
Horizon 160 Vertical 160
Horizon 160 Vertical 160
Horizon 160 Vertical 160
Horizon 160 Vertical 160
Average Power(Watts)/m²
~210
~150
~150
~280
~170
~150
Max Power(Watts)/m²
~420
~320
~310
~680
~350
~310
Lifetime (hrs)
100,000
100,000
100,000
100,000
100,000
100,000
Operating Temperature
-10℃ ~ +45℃
-10℃ ~ +45℃
-10℃ ~ +45℃
-10℃ ~ +45℃
-10℃ ~ +45℃
-10℃ ~ +45℃
Operating Humidity
10% ~ 90%
10% ~ 90%
10% ~ 90%
10% ~ 90%
10% ~ 90%
10% ~ 90%
Refresh Rate (Hz)
3840 / 7680
3840 / 7680
3840 / 7680
3840 / 7680
3840 / 7680
3840 / 7680
Cabinet Weight/kg
4.5
4.5
4.5
4.5
4.5
4.5
